Underfloor heating only performs as well as the manifold and controls behind it. A well-balanced stainless steel manifold gets hot water where it needs to go — but it's the thermostat, wiring centre and actuators that decide when and how much. Engo Controls gives UK installers a genuinely flexible way to control a UFH system, whether that's a full smart wired setup, a wireless ZigBee install with no chased-in cabling, a simple hubless wired system, or an electric-mat retrofit in a single room.
This guide breaks down four affordable ways to pair Engo Controls thermostats with a stainless steel underfloor heating manifold, plus the wiring centres, actuators, gateways and installation accessories you'll need to finish the job properly.
Four Ways to Control Your Underfloor Heating
Every Engo Controls UFH setup starts with the same manifold — the difference is entirely in how the thermostats talk to the wiring centre. Here's how the four approaches compare before we go zone-by-zone.
1. Wired UFH (Smart Hub)
230V wired Engo ONE thermostats connect to an ECB8-230 wiring centre and E30NC-230 actuators, with an Egate-Pro-UK gateway added for full app and voice control. The most fully-featured option for new builds with first-fix cabling in place.
2. Wireless UFH (ZigBee)
The same Engo ONE thermostats communicate over ZigBee 3.0 to an ECB62-ZB wireless control box — no core cabling between rooms and the manifold cupboard. Ideal for retrofits, extensions and rooms where chasing walls isn't an option.
3. Wired Hubless UFH
EONE-16W or EONE-16B thermostats wire directly to an ECB8-230 wiring centre, or drive electric mats directly via their own built-in 16(2)A relay — no separate ZigBee gateway or control box needed for app control.
4. Electric UFH
For tiled rooms without wet pipework, an EONE-16 electric thermostat pairs with 150W/m² peel-and-stick heating mats for a fast, low-disruption single-room retrofit.
Why the Manifold and the Controls Have to Be Chosen Together
A stainless steel manifold with 2 to 12 ports sets how many independent zones your system can run — but each port needs an actuator, and each actuator needs a signal from a thermostat via a wiring centre. Undersizing the wiring centre for the manifold you've fitted is one of the most common UFH snagging issues on site.
Rule of thumb: match your wiring centre zone count to your manifold port count, and choose wired, wireless or hubless Engo controls based on how much first-fix cabling is realistically achievable in that property.
Engo Controls UFH Systems Compared
| System | Thermostat | Wiring Centre | Actuator | Gateway | Best For |
|---|---|---|---|---|---|
| Wired (Smart Hub) | EONE-230W / E40-230W | ECB8-230 | E30NC-230 | Egate-Pro-UK | New builds, full app control |
| Wireless (ZigBee) | EONE-230W / E40-230W / EONE-BATW | ECB62-ZB | E30NC-230 | Egate-Pro-UK | Retrofits, no cable runs |
| Wired Hubless | EONE-16W / EONE-16B | ECB8-230 | E30NC-230 | None required | Simple, budget installs |
| Electric | EONE-16 | N/A — direct to mat | N/A | None required | Single tiled rooms |
Wired UFH: Engo ONE Thermostats, ECB8-230 Wiring Centre & Egate-Pro-UK Gateway
The wired smart setup is the most complete Engo Controls UFH system. The EONE-230W (or the more compact E40-230W) mounts flush on the wall and connects directly to the ECB8-230 wiring centre, which in turn drives an E30NC-230 actuator on each manifold port. Add the Egate-Pro-UK gateway and every zone gets app scheduling, temperature history and Alexa or Google Assistant voice control — all while continuing to work locally if the internet drops.
Engo Controls
EONE-230W ZigBee Smart Thermostat, 230V Wired
Flush-mounted 230V thermostat with humidity sensor, volt-free COM/NO relay output and TPI control, ideal for underfloor heating. Pairs with the Egate-Pro-UK gateway for full app and voice control.
£65.00 Inc. VAT
Engo Controls
E40-230W 230V Wired ZigBee Smart Thermostat
Mains-powered 230V ZigBee 3.0 / 868MHz thermostat — a more compact alternative to the EONE-230W for tighter wall spaces, with the same wiring centre compatibility.
£49.95 Inc. VAT
Engo Controls
EONE-BATW Battery-Powered ZigBee Thermostat
Rechargeable Li-Ion battery model, USB-C charging, no mains wiring at the thermostat. Sits alongside wired EONE-230W stats on the same ECB8-230 or ECB62-ZB system for rooms without a supply cable.
£65.00 Inc. VAT
Engo Controls
ECB8-230 Wired Control Box, 8 Zones
Wired 8-zone wiring centre with integrated pump and boiler control modules. Manages the circulation pump automatically and triggers the heat source via a volt-free relay. Pairs with EONE-230W, E40-230W and EONE-16 series thermostats.
£52.90 Inc. VAT
Engo Controls
E30NC-230 Thermal Actuator, M30x1.5
Normally-closed 230V thermal actuator with an M30x1.5 thread, fitting the vast majority of UK and European UFH manifolds. Just 2W running power, IP54 rated, opening and closing the loop on the wiring centre's signal.
£13.00 Inc. VAT
Engo Controls
Egate-Pro-UK ZigBee 3.0 Gateway
Professional-grade ZigBee 3.0 gateway with external antenna for extended range through concrete floors and partition walls. Connects via Wi-Fi or LAN — unlocks full ENGO Smart app scheduling and Alexa/Google voice control.
£65.00 Inc. VAT
Wireless UFH: Same Engo ONE Thermostats, ECB62-ZB Control Box
Where cabling between rooms and the manifold cupboard isn't practical — a barn conversion, an extension, or a retrofit into an existing screed floor — the wireless system swaps the ECB8-230 for the ECB62-ZB. It's the same EONE-230W, E40-230W and EONE-BATW thermostats, communicating over ZigBee 3.0 instead of a physical wire, with actuators still switched locally at the manifold.
Engo Controls
ECB62-ZB ZigBee Smart Control Box, 6 Wireless + 2 Wired
8-zone capacity (6 wireless, 2 wired) ZigBee 3.0 UFH control box. The wireless zones bind directly to Engo EONE or E25 thermostats — no cable runs between rooms and the manifold cupboard.
£99.95 Inc. VAT
Engo Controls
EONE-BATW Wireless Battery Thermostat
Surface-mounted, rechargeable Li-Ion thermostat — binds directly to the ECB62-ZB with no gateway needed for basic offline heating control, or full app control when paired with Egate-Pro-UK.
£65.00 Inc. VAT
Engo Controls
EONE-230W Wired ZigBee Thermostat
In wireless installs the thermostat itself still wires to mains locally, but talks to the ECB62-ZB over ZigBee — no long cable runs across the property.
£65.00 Inc. VAT
Engo Controls
E30NC-230 Thermal Actuator
The same normally-closed M30x1.5 actuator used across all Engo wired and wireless systems — fits every manifold port regardless of which control box is driving it.
£13.00 Inc. VAT
Wired UFH Hubless: EONE-16W & EONE-16B with ECB8-230
The EONE-16 series is Engo's Wi-Fi-enabled wired thermostat range — available in white (EONE-16W) or black (EONE-16B) — with a built-in 16(2)A relay that can drive underfloor heating loads or electric heating mats directly, or signal the ECB8-230 wiring centre for a wet UFH manifold. Because the Wi-Fi module is built into the thermostat itself, there's no separate ZigBee gateway or ECB62-ZB control box needed for app control — a straightforward, self-contained option for wired zone-by-zone control.
Engo Controls
EONE-16W Wi-Fi Smart Thermostat, 16A Relay — White
Flush-mounted Wi-Fi thermostat with a built-in 16(2)A relay, built to drive underfloor heating and electric heating mats directly without an external contactor.
£68.95 Inc. VAT
Engo Controls
EONE-16B Wi-Fi Smart Thermostat, 16A Relay — Black
Identical spec to the EONE-16W in a black finish — flush-mounted, built-in 16(2)A relay, drives electric heating mats directly.
£68.95 Inc. VAT
Engo Controls
ECB8-230 Wired Control Box
The same wiring centre used in the smart wired system, but here paired directly with EONE-16 series thermostats for straightforward wired zone control with no separate ZigBee gateway needed.
£52.90 Inc. VAT
Electric UFH: EONE-16 Thermostat with 150W/m² Peel-and-Stick Mats
For a bathroom, ensuite or kitchen refurbishment where wet underfloor heating isn't practical, the EONE-16W / EONE-16B's built-in 16(2)A relay pairs directly with Engo's 150W/m² peel-and-stick electric heating mats. No manifold, no wiring centre, no separate actuators — just a floor sensor, the thermostat, and a mat that goes straight down under tile or stone.
Engo Controls
EONE-16W / EONE-16B Electric UFH Thermostat
Built-in 16(2)A relay switches electric heating mats directly — no external contactor needed. Available in white (EONE-16W) or black (EONE-16B).
£68.95 Inc. VAT
Quality Heating
Electric UFH Peel & Sticky Mats — 150W/m²
Full self-adhesive backing for fast, mess-free installation under tile and stone. Pairs directly with the EONE-16 thermostat for a complete single-room electric UFH system.
£40.00 Inc. VAT
The Manifold & Installation Accessories
Every wired or wireless system above still starts at the same place: a stainless steel manifold balancing flow to each zone, and a clean, secure pipe run getting there. Here's the manifold and the fixing accessories that complete the job.
Quality Heating
Stainless Steel UFH Manifold, 2–12 Port
Stainless steel manifold with pressure gauge and auto air vent, compatible with 12mm and 16mm pipe. Choose from 2 to 12 ports to match your wiring centre's zone count.
from £43.00 Inc. VAT
Quality Heating
Pipe Fixing Clips 40mm — Pack of 100
Strong grip barbed clips that secure UFH pipe firmly to insulation boards, keeping your pipe centres consistent along each run.
£7.00 Inc. VAT
Quality Heating
Pipe Fixing Clips 60mm — Pack of 100
The 60mm version for thicker insulation boards — same high-grip barbed design, firmly securing pipe to the board before screed or floor covering goes down.
£7.95 Inc. VAT
Quality Heating
Pipe Clip Tacker with Inspection Flap
Speeds up fixing pipe clips to insulation boards while reducing installer fatigue on long runs. The inspection flap lets you check clip placement without breaking rhythm.
£89.00 Inc. VAT
Full Specification Reference
| Product | Type | Connectivity | Power | Warranty |
|---|---|---|---|---|
| EONE-230W | Thermostat, wired | ZigBee 3.0 (via Egate-Pro-UK) | 230V mains | 5 years |
| E40-230W | Thermostat, wired | ZigBee 3.0 (via Egate-Pro-UK) | 230V mains | 5 years |
| EONE-BATW | Thermostat, wireless | ZigBee 3.0 | Rechargeable Li-Ion (USB-C) | 5 years |
| EONE-16W / EONE-16B | Thermostat, hubless wired | None (direct wire) | 230V mains | 5 years |
| EONE-16 | Electric UFH thermostat | None (direct wire) | 230V mains | 5 years |
| ECB8-230 | Wiring centre, wired | None (direct wire) | 230V mains | 5 years |
| ECB62-ZB | Wiring centre, wireless | ZigBee 3.0 | 230V mains | 5 years |
| E30NC-230 | Thermoelectric actuator | None (direct wire) | 230V, ~2W | 5 years |
| Egate-Pro-UK | ZigBee gateway | Wired / 2.4GHz Wi-Fi | 230V mains | 5 years |
| UFH Manifold, 2–12 Port | Stainless steel manifold | N/A | N/A | Standard |
| Peel & Sticky Mat, 150W/m² | Electric heating mat | N/A | 230V mains | Standard |
Frequently Asked Questions
Do I need the Egate-Pro-UK gateway for wired or wireless Engo UFH control?
No. The ECB8-230 (wired) and ECB62-ZB (wireless) wiring centres will both run a full underfloor heating system on their own. The Egate-Pro-UK gateway is only needed if you want ENGO Smart app scheduling, remote access, temperature history or Alexa/Google voice control.
Can I mix wired and battery thermostats on the same system?
Yes. The EONE-BATW battery thermostat and the wired EONE-230W or E40-230W can sit on the same ECB62-ZB wireless control box, so you can use battery stats in rooms without a supply cable and wired stats elsewhere.
What's the difference between the wired hubless system and the smart wired system?
Both use the ECB8-230 wiring centre and E30NC-230 actuators. The smart system adds ZigBee-capable EONE-230W or E40-230W thermostats plus the Egate-Pro-UK gateway for app control. The hubless system uses the EONE-16W/EONE-16B thermostats, which have Wi-Fi and a 16(2)A relay built directly into the unit — so app control is available without adding a separate ZigBee gateway or control box.
How many ports do I need on my underfloor heating manifold?
One port per heating zone/loop, matched to your wiring centre's zone capacity. The stainless steel manifold above is available from 2 to 12 ports, so it's worth confirming the room count and loop lengths before ordering.
