Vaillant VR92 Wired Remote Control | 0020260925 | eBUS sensoCOMFORT
Regular price
£117.00
Inc. VAT
£97.50
Exc. VAT
FREE Express Delivery (1-3 days) in UK Mainland on most orders*
Excluding: Solar Panels (£170 delivery / free above £2,500), Batteries (£39 delivery), Small Items (£4.95/5.95 delivery / free above £500)
Contact Us to check for Next Working Day Delivery or Same-day Delivery options
Contact Us for Click & Collect options
Custom quote available on request
*See checkout or shipping policy for full details
Payment options
Tools & Kits
Build your kit
Need a full system?
Design your complete solution in minutes with our kit builders.
Do you have a question
about this product?
One of our expert advisors will be happy to help you!
Contact Us
The Vaillant VR92 is a wired remote room control designed to extend the capabilities of a sensoCOMFORT VRC 720 heating system. Connecting via a two wire eBUS link, it provides independent temperature control and scheduling for additional heating zones, making it ideal for larger homes, multi zone installations and professional heating system upgrades.
With its clear 3.5 inch backlit TFT display, intuitive menu structure and support for up to 12 time programmes per day, the VR92 helps householders maintain comfortable temperatures while supporting efficient system operation. It is a practical choice for installers specifying reliable, manufacturer matched controls for Vaillant heating and renewable systems.
eBUS
2 wire connection
24V
Operating voltage
3.5"
Backlit TFT display
12
Programmes per day
IP20
Protection rating
109 x 175
Dimensions, mm (H x W)
Useful information: The VR92 is a wired additional zone control. It is intended for use alongside a Vaillant sensoCOMFORT VRC 720 system controller and is not a standalone room thermostat.
Compatibility note: The VR 92 requires a compatible sensoCOMFORT VRC 720 wired system controller. It is not compatible with the wireless sensoCOMFORT VRC 720f for wireless systems, the VR 92f is the corresponding remote control.
Safety and installation: Installation and electrical connections must be carried out by a competent, qualified installer in accordance with the manufacturer’s instructions and current UK wiring requirements, including BS 7671.
Key Features
Multi Zone Heating Control
Provides independent control for an additional heating zone when used with a sensoCOMFORT VRC 720, supporting up to four VR92 controls in a compatible wired configuration.
Clear TFT Display
The 3.5 inch monochrome backlit TFT display presents temperatures, status information and menu options clearly, with text and symbols available in 33 languages.
Flexible Time Programming
Create a weekly heating schedule with up to 12 time periods per day, each with its own selected target temperature, plus night setback and absence functions.
Simple eBUS Wiring
Connects using a low voltage two wire eBUS connection, with a recommended minimum cable cross section of 0.75 mm² and a maximum eBUS cable length of 125 m.
Installer Friendly Setup
An integrated installation assistant helps speed up commissioning, while the wall mounted design allows neat, accessible placement in the controlled zone.
Comfort and System Insight
Features include a Quick Veto temporary temperature override, operating status display, next service reminder and humidity based cooling support where applicable.
Technical Specifications
Compatibility
The Vaillant VR 92 is designed for use with Vaillant heating and renewable systems that use eBUS communication in conjunction with the sensoCOMFORT VRC 720 system controller. Suitable applications include compatible ecoTEC boilers, aroTHERM air to water heat pumps, flexoTHERM and flexoCOMPACT heat pumps, and selected geoTHERM ground source heat pumps.
In a maximum wired configuration, up to four VR 92 remote controls can be used with a VRC 720, with one VR 92 allocated per heating circuit. The system can support up to nine direct and/or mixed heating circuits when configured with the appropriate Vaillant control modules.
