Vaillant sensoHOME VRT380 Wired Room Thermostat | 0020260951 | eBUS

Description

Take control of everyday comfort with the Vaillant sensoHOME VRT380 wired room thermostat. Designed for compatible Vaillant eBUS heating systems, it combines a clear touch interface with flexible weekly programming, helping homeowners match heating to their routine while giving installers dedicated commissioning and configuration tools.

Set individual comfort temperatures with up to 12 heating periods per day, make temporary adjustments and manage domestic hot water where supported by the installed system. Its wired eBUS connection enables modulating control, allowing the heating system to adjust its operation to demand rather than relying solely on basic on/off switching.

eBUS

Wired connection

9-24 V

Rated voltage

12 per day

Heating periods

IP20

Ingress protection

175 mm

Width

Class III

Electrical protection

Installation safety: Electrical installation must be carried out by a qualified electrician. The heating installation must be decommissioned before work begins. Use the specified eBUS connection and follow the installation instructions.

Compatibility: This is the wired VRT380, not the wireless VRT 380f. It is intended for compatible Vaillant eBUS heat generators, it is not a universal replacement for a mains switching thermostat. Available functions depend on the installed system.

ErP documentation difference: The product data sheet lists control class V and a 3.0% contribution to seasonal room heating efficiency. The installation manual lists class VI and 4.0% for weather compensated control with the room thermostat function enabled. These are configuration dependent figures, not guaranteed energy bill savings, confirm the applicable classification for the installation.

Positioning tip: Keep the room thermostat clear of furniture and curtains. Where it controls the room temperature, the manual instructs users to keep that room’s thermostatic radiator valves fully open.

Key features

Modulating eBUS control

The wired eBUS interface supports modulating control of compatible Vaillant heating equipment, helping match heat delivery to the system’s requirements.

Flexible weekly schedules

Create up to 12 heating periods per day, each with its own desired temperature. Set back settings manage heating outside scheduled periods.

Straightforward touch interface

Use the touch controls to navigate menus, adjust temperatures and access help. A button lock helps prevent unintended changes.

Guided commissioning

The installation assistant guides the installer through configuration. Dedicated installer settings allow the control to be matched to the heating installation.

Hot water management

Control domestic hot water schedules and request a one off cylinder boost where the system supports these functions. Hot water and circulation planners each allow up to three periods per day.

Weather compensated operation

With a suitable outdoor temperature sensor, the control can use weather compensation and an installer configured heat curve to adjust target flow temperature.

Technical specifications

Product identification

Brand

Vaillant

Product range

sensoHOME

Model

VRT380 - wired

Manufacturer part number

0020260951

Product type

Programmable wired room thermostat / system control

Electrical and protection

Communication

Vaillant eBUS

Rated voltage

9-24 V

Rated current

Less than 50 mA

Rated surge voltage

330 V

Supply conductor cross-section

0.75-1.5 mm²

Maximum bus cable length

125 m

IP rating

IP20

Protection class

III

Pollution degree

2

Mode of operation

Type 1

Dimensions and operating environment

Dimensions (H × W × D)

109 × 175 × 26 mm

Permitted ambient temperature

0-60 °C

Room air humidity

35-95%

Ball pressure test temperature

75 °C

Installation

Wall mounted, do not install in rooms prone to frost

Programming and system functions

Heating weekly planner

Up to 12 time periods and desired temperatures per day

Domestic hot water weekly planner

Up to 3 time periods per day, system dependent

Circulation weekly planner

Up to 3 time periods per day, system dependent

Heating modes

Manual, time controlled and off

Additional functions

Absence, domestic hot water boost, ventilation boost and button lock, availability depends on system configuration

Weather compensation

Requires a suitable connected outdoor temperature sensor

Heat curve adjustment

0.1-4.0

Compatibility

Compatible Vaillant heat generators with eBUS, system design and commissioning determine supported functions

Compliance and energy classification

CE marking

Confirmed in operating and installation instructions

ErP product data sheet

Class V, 3.0% seasonal room heating efficiency contribution

Manual: weather-compensated configuration

Class VI, 4.0% contribution with room thermostat function enabled, see documentation callout

Frequently asked questions

Is the sensoHOME VRT 380 wired or wireless?

The VRT 380 is wired and communicates through Vaillant eBUS. It should not be confused with the VRT 380f wireless version.

Will this thermostat work with any boiler?

No. It is intended for compatible Vaillant heat generators with an eBUS interface. Ask your installer to check the exact boiler and system configuration before ordering; it is not a universal mains switching thermostat.

Can I set different heating temperatures throughout the day?

Yes. The weekly planner supports up to 12 heating periods per day, each with its own desired temperature. Outside these periods, operation follows the configured set-back mode.

Can it control my hot water as well as the heating?

On suitable systems, it provides domestic hot water scheduling, circulation scheduling and a one off cylinder boost. These functions depend on the connected equipment and installation configuration.

Does weather compensation require an outdoor sensor?

Yes. Weather compensated control requires a suitable connected outdoor temperature sensor. The installer configures the heat curve and relevant room temperature settings for the building.

Where should the room thermostat be installed?

Install the wall mounted control in an appropriate room according to the manual, away from obstructions such as curtains and furniture. Do not install it in a room prone to frost; electrical installation requires a qualified electrician.
