SolarEdge Home Battery 10kWh Battery v02 400V

SolarEdge Home Battery 10kWh v02 (400V)

The SolarEdge Home Battery 10kWh v02 (400V) is a high-voltage, DC-coupled lithium-ion energy storage system designed for seamless integration with SolarEdge Home Hub/Wave and StorEdge inverters. It enables maximized solar self-consumption, robust backup power, and is managed through a single SolarEdge app for production, consumption, and storage optimization. The battery meets the strictest global fire safety standards (UL9540A, IEC62619) and is suitable for both indoor and outdoor installation, with flexible wall or floor mounting options.

Key Features

• Usable Energy (100% DoD): 9.7 kWh
• Continuous Output Power: 5,000 W
• Peak Output Power (10 sec backup): 7,500 W
• Roundtrip Efficiency: 94.5%
• Voltage Range: 350–450 V DC
• Max. Continuous Output Current: 14.3 A
• Battery Chemistry: NMC (Nickel Manganese Cobalt)
• Depth of Discharge: 100%
• Compatible Inverters: SolarEdge Home Hub/Wave (single phase), StorEdge HD-Wave, SolarEdge Home Short String Inverter
• Max. Batteries per Inverter: Up to 3 (model dependent)
• Communication: Wireless and RS485
• App Control: Unified SolarEdge app for monitoring and management
• Fire Safety: UL9540A, IEC62619, UN38.3 certified
• Warranty: 10 years

Technical Specifications

• Dimensions (W x H x D): 790 × 1179 × 250 mm
• Weight: 119–121 kg
• Mounting: Floor or wall mount
• Ingress Protection: IP55 (indoor/outdoor)
• Operating Temperature: -10°C to +50°C
• Noise Level: <25 dBA @1m
• Cooling: Natural convection
• Max. Installation Altitude: 2,000 m
• Storage Temperature: -10°C to +30°C (long-term), -30°C to +60°C (short-term)

Additional Information

• Part Code: SE-BATTERY02-10KWH / BAT-10K1PS0B
• Made to order: Cannot be returned or cancelled
• Safety: Rapid Shutdown and SafeDC™ technology
• Installation: Plug-and-play, SetApp-based configuration

Note: For backup power, an inverter with backup capability is required. Professional installation is recommended.
