Schletter Roof Hook Rapid2+ 35, ProLine | 101002-020

Description

This Schletter Rapid2+ roof hook is built for the ProLine range at a 35mm fork height, suited to roofs with lower battens where the standard 45mm hook height would sit the rail too high.

Manufactured in welded stainless steel with a symmetric bar arrangement, it is pre-assembled for straightforward fitting, and uses a rotatable multi-adapter to connect to both ProLine and classic Schletter rail systems.

35mm

Fork Height, Low Battens

110mm

Base Plate Width

108mm

Overall Height

150mm

Hook Width

Stainless Steel

Material

Welded

Construction

Key Features

35mm Fork Height for Low Battens

Specifically sized with a 35mm fork height, suiting roofs with lower battens where a standard-height hook would sit the mounting rail too high.

Symmetric Bar Arrangement

Features a symmetric, welded bar arrangement, giving consistent, balanced load transfer into the rafter.

Rotatable Multi-Adapter

The rotatable adapter connects to both ProLine series profiles and the classic Schletter modular system from a single hook.

Welded Stainless Steel Construction

Built from welded stainless steel, giving strong corrosion resistance and structural rigidity for long-term outdoor performance.

Pre-Assembled for Fast Fitting

Arrives pre-assembled, reducing on-site setup time before fixing to the rafter.

Please Note

Wood screws are not included and must be ordered separately to complete the fixing.

Technical Specification

Roof Hook Specification

Fork Height

35 mm (for low battens)

Base Plate Width

110 mm

Overall Height

108 mm

Base Plate Length

60 mm

Hook Width

150 mm

Bar Arrangement

Symmetric

System Compatibility

ProLine series and classic Schletter modular system, via rotatable multi-adapter

Assembly

Pre-assembled, welded construction

Materials

Material

Stainless steel

Frequently Asked Questions

What roof configuration is the 35mm fork height suited to?

It's designed for roofs with lower battens, where a standard 45mm fork height hook would sit the mounting rail too high above the tile line.

What rail systems does this hook connect to?

Via its rotatable multi-adapter, it connects to both ProLine series profiles and the classic Schletter modular system.

Is this hook pre-assembled?

Yes, it arrives pre-assembled with a welded, symmetric bar arrangement.

Does this hook include fixing screws?

No, wood screws must be ordered separately to complete the installation.

What material is this hook made from?

It's manufactured in stainless steel with welded construction.
