Scame Heat Pump AC Isolator | 32A 3-Pole | IP66/IP69 Grey

Description

This Scame 32A three-pole AC isolator is purpose-selected for external installation adjacent to heat pumps, giving installers a compact, lockable disconnection point that meets the weatherproofing demands of outdoor heat pump siting. Rated IP66/IP69, it stands up to jet washing, driving rain and sustained outdoor exposure without compromising the switch mechanism.

Built to EN 60947-3 as a switch-disconnector, the isolator can be padlocked in either the on or off position — an essential safe-isolation feature for engineers working on heat pump outdoor units. Its low-profile, more attractive housing design distinguishes it from typical utilitarian isolators, making it a neater fit next to a heat pump than many competing general-purpose enclosures.

32A

Rated current

3-Pole

Configuration

690V

Rated voltage

IP66/IP69

Ingress protection

IK09

Impact resistance

650°C

Glow wire rating

Good to Know

This isolator is rated for circuits up to 32A on three-phase supplies and can be padlocked in either the off or on position for safe isolation during maintenance and commissioning work.

Key Features

Lockable Off/On Positions

Can be padlocked in the off or on position, supporting safe isolation procedures during heat pump servicing and commissioning.

High Ingress Protection

Rated IP66/IP69, suitable for exposed external locations subject to heavy rain, dust and pressure washing.

Impact Resistant Housing

IK09 impact rating and a glow wire rating of 650°C give robust protection against mechanical knocks and fire risk.

Purpose-Selected for Heat Pumps

Specially selected for external installation adjacent to heat pumps, with a more attractive housing design than typical competitor isolators.

Engineering Plastic Construction

Durable engineering plastic housing in grey/black, built to withstand sustained outdoor exposure.

Compliant Switch-Disconnector

Manufactured to EN 60947-3 and EN 60947-1 switchgear standards under the EU Low Voltage Directive.

Technical Specification

Electrical

Rated Current

32A

Poles

3P

Rated Voltage

690V

Switch Size

Y1

Protection & Materials

Ingress Protection

IP66 / IP69

Impact Protection (IK)

IK09

Glow Wire Rating

650°C

Material

Engineering plastic

Colour

Grey/Black

Physical

Dimensions (W x H x D)

110 x 150 x 87mm

Flange Size

106 x 150mm

Product Type

Switch disconnector, general lockable isolator

Standards

Switchgear Standard

EN 60947-3 (switches, disconnectors, switch-disconnectors)

General Rules Standard

EN 60947-1

Directive

Low Voltage Directive 2014/35/EU

Frequently Asked Questions

What is the maximum current rating of this isolator?▼

This isolator is rated at 32A on three-phase (3-pole) circuits, suitable for the electrical supply requirements of most domestic and light commercial heat pump installations.

Can this isolator be locked?▼

Yes. It can be padlocked in either the off or on position, supporting safe isolation practices during installation, commissioning and maintenance work.

Is it suitable for outdoor installation?▼

Yes, it is rated IP66/IP69 and specifically selected for external installation adjacent to heat pumps, giving high resistance to rain, dust and pressure washing.

What standards does the isolator meet?▼

It is manufactured to EN 60947-3 (switches, disconnectors and switch-disconnectors) and EN 60947-1, in compliance with the EU Low Voltage Directive 2014/35/EU.

What are the physical dimensions?▼

The isolator measures 110 x 150 x 87mm with a flange size of 106 x 150mm.
