Phono Solar 420W Draco Module N-TopCon Mono BM6-16B-G – Bifacial Dual Glass All Black

Phono Solar 420W Draco Module N-TopCon Mono BM6-16B-G – Bifacial Dual Glass All Black

The Phono Solar 420W Draco Module N-TopCon Mono BM6-16B-G is a high-performance, bifacial dual glass solar panel designed for maximum durability and efficiency. Utilising advanced N-Type TOPCon monocrystalline cell technology, this module delivers reliable power output, excellent low-light performance, and enhanced energy yield from both the front and rear sides.

The dual glass construction increases longevity and resistance to environmental factors, while the all-black design ensures a sleek, modern aesthetic suitable for residential and commercial rooftops. This panel is certified to the latest international standards and is built to withstand harsh weather conditions.

Key Features

• Rated Power (Pmax): 420W
• Cell Type: N-Type TOPCon, 108 half-cut monocrystalline cells
• Module Efficiency: ~21–22%
• Bifacial dual glass construction for increased energy yield and durability
• All-black design for premium aesthetics
• Maximum System Voltage: 1500V
• Series Fuse Rating: 30A
• Operating Temperature Range: -40°C to +85°C
• Temperature Coefficient (Pmax): -0.29%/°C
• Dimensions: 1722 × 1134 × 30 mm
• Weight: 21 kg
• Frame: Anodized aluminium, all black
• Junction Box: IP68 rated
• Connector: MC4 compatible
• Product Warranty: 20 years
• Performance Warranty: 30 years (87.4% output at year 30)
• Certifications: IEC 61215, IEC 61730, ISO 9001, ISO 14001, ISO 45001

Technical Specifications

• Maximum Power (Pmax): 420W
• Open Circuit Voltage (Voc): 38.72 V
• Short Circuit Current (Isc): 14.09 A
• Maximum Power Voltage (Vmpp): 32.47 V
• Maximum Power Current (Impp): 12.94 A
• Module Efficiency: 21.51%
• Power Tolerance: 0~+5W
• NOCT: 45±2°C
• Operating Temperature: -40°C ~ +85°C
• Maximum System Voltage: 1500V DC
• Maximum Series Fuse Rating: 30A
• Fire Rating: Class C

Note: This panel is suitable for both residential and commercial installations and is compatible with all leading inverter brands and mounting systems.
