Fusebox 40A EV Metal Clad Distribution Board with Bi-Directional RCBO and Type 2 SPD
The Fusebox EV40ABDZ is a robust metal clad distribution board designed specifically for electric vehicle (EV) charging installations. This unit features a 40A 30mA Type A bi-directional RCBO for comprehensive earth fault protection, a 100A main switch for reliable circuit control, and a Type 2 surge protection device (SPD) to safeguard against voltage spikes. With an IP-rated metal enclosure and compliance with the 18th Edition Amendment 2, this distribution board ensures safety, durability, and compliance for EV charger circuits in both residential and commercial environments.
Key Features
- 40A 30mA Type A bi-directional RCBO for earth fault and overload protection
- 100A rated main switch for high current circuit isolation
- Type 2 direct-to-busbar surge protection device (SPD) for overvoltage protection
- Metal clad, IP-rated enclosure with top-hinged door for secure enclosure and easy access
- 18th Edition Amendment 2 compliant, ensuring up-to-date electrical safety standards
- Designed specifically for internal wiring applications with EV chargers
- Compact dimensions suitable for residential and commercial EV charging electrical setups
Technical Specifications
| Model | EV40ABDZ |
|---|---|
| Current Rating | 40A RCBO, 100A main switch |
| RCBO Type | Type A, 30mA, Bi-Directional |
| Surge Protection | Type 2 SPD (direct to busbar) |
| Enclosure Material | Metal clad, IP Rated |
| Dimensions | 259mm (H) x 162mm (W) x 113mm (D) |
| Door Type | Top hinged |
| Frequency | 50/60 Hz |
| Compliance | 18th Edition Amendment 2 Electrical Regulations |
| Application | EV charging installation protection for residential/commercial |
| Warranty | Manufacturer standard warranty |
Applications
- Comprehensive electrical safety and protection for EV charging circuits
- Integration into EV charger electrical infrastructure in residential and commercial sectors
- Protection against earth faults, overloads, and power surges in EV installations
Why Choose EV40ABDZ?
- Robust and reliable protection components in a compact metal enclosure
- Compliant with latest electrical safety regulations for EV chargers
- Integrated surge protection enhances durability of connected equipment
- Easy installation and maintenance with top-hinged door and clear labeling
- Type EV Charging Accessories
- Vendor Fusebox
- SKU EV40ABDZ
