ESBE MBA121 2 Way Motorised Ball Valve Internal Thread, 230V

Description

The ESBE MBA121 DN25 motorised ball valve provides dependable on/off flow control for heating and cooling systems. With a high flow DN25 body, 230V actuator and air bubble tight shut-off, it is a practical choice for homeowners upgrading a heating system and for installers requiring a reliable zone control valve.

Its compact actuator operates with a simple 2 point SPST signal, while the anti condensation resistor helps protect the internal electronics. The valve delivers a Kvs flow rate of 60 m³/h and is suitable for water based heating and cooling circuits with media temperatures from 0°C to 90°C.

Key Features

High Flow DN25 Control

A 25mm nominal bore and 60 m³/h Kvs value support efficient flow control in larger heating and cooling circuits.

Reliable 230V Actuator

The 230V AC, 50Hz actuator uses a 2 point SPST control signal for straightforward open/close operation.

Air Bubble Tight Shut Off

Engineered to EN 12266-1 leakage rate A, helping to prevent unwanted internal leakage when the valve is closed.

Anti Condensation Protection

An integrated anti condensation resistor helps reduce moisture build up around the actuator electronics.

Easy Actuator Removal

A metallic spigot connection allows the actuator to be fitted or removed quickly and securely during installation or servicing.

Suitable for Heating & Cooling

Designed for water based heating and cooling applications, with a media temperature range of 0°C to 90°C.

Technical Specifications

Specification	Details
Product Model	ESBE MBA121
MPN	43100200
Valve Type	2 way motorised ball valve
Nominal Diameter	DN25 / 25mm
Connection	G1" internal thread
Kvs Flow Rate	60 m³/h
Pressure Class	PN32
Working Pressure	3.2 MPa / 32 bar
Media Temperature Range	0°C to 90°C
Power Supply	230V AC ±10%, 50Hz
Power Consumption	3.5W during motor operation, up to 5W for anti condensation resistor
Control Signal	2 point SPST
Actuator Torque	10Nm
Running Time	40 seconds for 90° rotation
Auxiliary Switch Rating	6A, 230V AC
Enclosure Rating	IP44
Protection Class	Class II
Connection Cable	0.85m attached cable
Weight	0.93kg
Leakage Standard	EN 12266-1, air bubble tight, leakage rate A

Ideal Use Cases

Home heating systems: Ideal for controlling flow to heating zones, underfloor heating manifolds, radiators or buffer vessels where automated on/off operation is required.

Cooling circuits: Suitable for water based cooling installations requiring dependable isolation and automated flow control.

Trade installations: A compact, service friendly valve for plumbers, heating engineers and renewable energy installers working on domestic or light commercial systems.
