Duracell Energy Dura-i 3.6kW Single-Phase Hybrid Inverter

Duracell Energy Dura-i 3.6kW Single-Phase Hybrid Inverter

The Duracell Energy Dura-i 3.6kW Single-Phase Hybrid Inverter is a highly efficient, versatile inverter designed to optimise residential and small commercial solar PV systems. With seamless integration of solar, battery storage, and grid interaction, it is ideal for both new installations and retrofits.

Key Features

• Nominal AC output power: 3.6kW
• Maximum PV to AC efficiency: 97.3%
• Compatible with Duracell Dura5 5.12kWh Outdoor Battery and other Duracell Energy batteries
• Modular design: connect up to 6 inverters in parallel for higher capacity
• Dual MPPTs for flexible string design (2 MPPTs, 1 string per MPPT)
• Wide MPPT voltage range: 70–540V (start-up voltage: 90V)
• Maximum PV input power: 9,000W
• Maximum PV input voltage: 550V
• Maximum charge/discharge current: 60A
• Maximum battery charge/discharge power: 3,000W
• Integrated energy meter for real-time monitoring of production and consumption
• AC-coupled and hybrid operation for flexible system design
• Wall-mount installation with a compact footprint
• IP65 protection for indoor or outdoor use
• Weight: 25kg
• Dimensions: 585 × 485 × 175 mm
• Standard 5-year warranty (extendable to 10 years)

Technical Specifications

• AC Output Power: 3,600 VA
• Output Current: 13.1A
• Rated Voltage: 230V
• Number of MPPTs: 2
• Strings per MPPT: 1
• Max. PV Input Power: 9,000W
• Max. PV Voltage: 550V
• Max. Charge/Discharge Current: 60A
• Max. Battery Charge/Discharge Power: 3,000W
• Protection: IP65
• Dimensions: 585 × 485 × 175 mm
• Weight: 25kg
• Warranty: 5 years (extendable to 10 years)

Applications

• Residential and small commercial solar PV systems
• New solar-plus-storage installations
• Retrofitting battery storage to existing solar arrays
• Flexible grid-tied and off-grid energy management
