Salus RX10RF Smart Home Boiler System Receiver

Salus RX10RF Smart Home Boiler System Receiver

The Salus RX10RF is a versatile smart boiler receiver designed for integration into the Salus iT600 Smart Home system, offering remote on/off control of boilers or individual heating zones. This receiver is compatible with both volt-free and 230V applications and uses ZigBee wireless technology for reliable communication with Salus thermostats and smart devices. With a manual override function, LED status indicators, and simple installation, it is suitable for use in a wide range of domestic and light commercial settings.

Technical Information

• Product Type: Wireless Boiler Receiver
• Power Supply: 230V AC, 50Hz
• Switching Capacity: Maximum 16 (5) A, SPST
• Output: Volt free contacts (NO/COM), 0–230V
• Wireless Protocol: ZigBee 2.4GHz
• Communication Range: Up to 30 metres (open space)
• Manual Override: On-board mode switch for immediate manual control
• Status Indication: LED indicators for pairing, status, and operation
• Mounting: Wall
• Dimensions: 145 mm (W) x 100 mm (H) x 35 mm (D)
• Ingress Protection: IP20 (indoor use)
• Operating Temperature: 0°C to 50°C
• Warranty: 5 years

Suitable For

• Remote on/off control of boilers in domestic and small commercial heating systems
• Integration with Salus Smart Home devices for automated heating management
• Use as an individual heating zone receiver or external boiler switch
• Compatible with underfloor heating wiring centres (KL08RF) and smart TRVs (TRV10RFM)

Key Features

• Switching for both volt free and 230V applications
• ZigBee wireless communication for stable system integration
• Manual control mode with easy-to-use override switch
• LED indicators to show system and boiler status
• Quick and simple wall-mounted installation
• Supports multi-zone heating when paired with compatible Salus thermostats and smart devices

Package Contents

• Salus RX10RF Boiler Receiver
• Mounting screws and terminal block
• Quick start guide / installation instructions
