Salus Elypso EL600F Smart Thermostat - Zigbee 3.0, Rechargeable Battery, for UFH & Radiator Heating

The Salus Elypso EL600F Smart Thermostat is a sleek, app-controlled Zigbee 3.0 smart thermostat designed for precise temperature management in underfloor heating, radiator, and electrical heating systems, seamlessly integrating with the SALUS Smart Home ecosystem.

Product Description

The Salus Elypso EL600F is a modern wireless thermostat featuring a rechargeable Li-Ion battery, full-colour touchscreen, and intuitive controls. It connects via Zigbee 3.0 (2.4 GHz) to the SALUS Smart Home system, enabling remote control, scheduling, and energy monitoring through the SALUS Premium Lite app. Ideal for new builds and retrofits, it supports heating and cooling modes, open window detection, and adaptive learning for optimal comfort and efficiency. The elegant design allows wall or desk mounting with a choice of square or round backplates.

Key Features

• Zigbee 3.0 connectivity: Low-power, reliable wireless communication with SALUS Smart Home devices.
• Rechargeable battery: Built-in Li-Ion 3.7V battery for cordless operation.
• Smart app control: Full remote access, scheduling, and insights via SALUS Premium Lite app (requires UG600/UG800 gateway).
• Heating & cooling modes: Versatile for UFH, radiators, boilers, and air conditioning.
• Adaptive learning: Optimises schedules based on usage patterns.
• Open window detection: Automatically pauses heating to save energy.
• Boiler Plus compatible: Meets UK efficiency standards.

Technical Specifications

• Model: EL600F – Elypso Smart Thermostat.
• Power supply: Rechargeable Li-Ion 3.7V battery (USB-C charging).
• Wireless protocol: Zigbee 3.0 (2.4 GHz).
• Temperature range: 5°C to 35°C (adjustable hysteresis 0.1°C to 2°C).
• Control algorithm: Hysteresis or TPI (Time Proportional Integral).
• Switching: Volt-free relay (SPST), 5A @ 230V AC.
• Protection rating: IP20.
• Ambient temperature: 0°C to +40°C.
• Display: Full-colour 2.8" touchscreen.

Dimensions & Weights

• Width: 86 mm.
• Height: 86 mm.
• Depth: 22 mm (wall-mounted).
• Weight: 180 g.

System & Application Notes

• Ideal for underfloor heating, radiator systems, and smart home integration.
• Requires SALUS UG600 or UG800 gateway for full app functionality.
• Compatible with SALUS RX30RF boiler receiver and TRV heads.
• Wall or desk mounting options with square/round backplates included.
• Professional installation recommended for electrical connections.
• 2-year manufacturer warranty.
