Renusol VarioSole Bracket M10 Offset Connection - REN-420131 | L-Bracket for Hanger Bolt Fixing

Description

The Renusol VarioSole Bracket M10 Offset Connection (Part No: REN-420131) is an L-shaped mounting bracket designed for use with M10 hanger bolts within the Renusol VarioSole+ and VS+ pitched-roof mounting systems. Manufactured from Aluminium EN-AW-6063 T6, the bracket's offset design accommodates fixing points that are not directly in line with the rail, giving installers flexibility when working around structural obstructions or awkward rafter spacing.

This bracket is distinct from the standard straight M10 bracket (REN-420014): the offset L-shape geometry allows the hanger bolt fixing point and the rail connection to sit at different positions, useful where the ideal rafter fixing location doesn't align cleanly with the planned rail run.

Aluminium

Material

EN-AW-6063 T6

Alloy Grade

M10

Fixing Size

Offset L-Shape

Bracket Type

Hanger Bolt

Used With

VS+

System Compatibility

Compatibility Warning

Renusol mounting equipment must not be used with mounting equipment from other suppliers. Doing so would inevitably void the warranty of the mounting system.

Confirm Bracket Type Before Ordering

This offset bracket is a different component from the standard REN-420014 M10 bracket. The offset L-shape design is intended specifically for situations where the hanger bolt fixing point cannot sit directly in line with the mounting rail — confirm which bracket geometry your installation requires before ordering.

Key Features

Offset L-Bracket Geometry

The L-shaped offset design allows the hanger bolt fixing point and rail connection to sit at different positions, adding installation flexibility.

Aluminium EN-AW-6063 T6

Manufactured from Aluminium EN-AW-6063 T6, a structural-grade aluminium alloy offering strength with corrosion resistance for outdoor use.

Designed for M10 Hanger Bolts

Built to work with M10 hanger bolts, used to anchor the VarioSole+ system into timber substructure.

Useful for Awkward Fixing Positions

Gives installers a way to work around structural obstructions or rafter spacing that doesn't align directly with the planned rail run.

Compatible With VarioSole+ and VS+

Designed for use within the Renusol VarioSole+ and VS+ pitched-roof mounting systems.

Forms Part of a Complete Warrantied Assembly

As a genuine Renusol component, using this bracket keeps the installation within the parameters of the system design and warranty.

Technical Specifications

General

Part Number

REN-420131

Product Name

VarioSole Bracket M10 Offset Connection

Manufacturer

Renusol

System Compatibility

VarioSole+ / VS+

Construction

Material

Aluminium EN-AW-6063 T6

Bracket Type

Offset L-bracket

Fixing

Fixing Size

M10

Used With

M10 hanger bolt

Frequently Asked Questions

What's the difference between this bracket and the standard M10 bracket?

This is an offset L-shaped bracket (REN-420131), designed for fixing points that don't align directly with the rail. The standard straight bracket (REN-420014) is a separate, differently shaped part.

What size hanger bolt does this bracket use?

It is designed to work with M10 hanger bolts used to anchor the VarioSole+ system into the roof's timber substructure.

When would I need an offset bracket instead of a standard one?

The offset design is useful when the ideal hanger bolt fixing point — for example, a specific rafter position — doesn't line up directly with the planned mounting rail run.

What material is this bracket made from?

It is manufactured from Aluminium EN-AW-6063 T6, a structural-grade aluminium alloy suited to outdoor solar mounting use.

Can this bracket be used with hanger bolts or rails from another manufacturer?

No. Renusol mounting equipment must not be mixed with components from other suppliers, as doing so would void the system warranty.
