Renusol Solar Fastener for Steel Substructure 125mm/50mm - REN-900183 | Stainless Steel Purlin Clamp

Description

The Renusol Solar Fastener for Steel Substructure (Part No: REN-900183, 125/50) is a pre-assembled clamping fastener designed to secure solar PV mounting equipment directly to steel purlins and steel substructures, without the need for drilling into the steelwork. Manufactured entirely from stainless steel, the fastener clamps around the steel section using a hexagon socket setscrew.

With a clamping range of 60.0–105.0mm, this 125/50 variant suits mid-range steel purlin depths, and carries full MCS, TÜV, and DIBt building approval for use in certified UK solar PV installations.

60.0–105.0mm

Clamping Range

0.089kg

Weight

Stainless Steel

Material

M10

Screw Diameter

65mm

Thread Length

Z-14.4-555

DIBt Approval

Compatibility Warning

Renusol mounting equipment must not be used with mounting equipment from other suppliers. Doing so would inevitably void the warranty of the mounting system.

Check Clamping Range Before Ordering

This 125/50 variant suits a clamping range of 60.0–105.0mm. Renusol also offers 80/50, 100/50, 150/50, 160/50, and 200/50 variants covering clamping ranges from 15mm up to 180mm — always measure the steel section depth before ordering.

Key Features

No Drilling Into Steelwork

Clamps securely around the steel purlin or substructure using a setscrew, avoiding the need to drill into structural steel.

Full Stainless Steel Construction

Manufactured entirely from stainless steel for long-term corrosion resistance in exposed roof or ground-mount conditions.

DIBt Building Approval

Certified to DIBt Z-14.4-555, providing recognised structural approval for use in commercial and industrial installations.

Pre-Assembled Set

Supplied as a pre-assembled fastener set, reducing on-site assembly time.

Hexagon Head Screw Fixing

Uses an M10, 65mm-thread hexagon head screw for a secure, adjustable clamp onto the steel section.

Multiple Clamping Range Variants

Available in several clamping range variants (80/50 through to 200/50) to suit different steel purlin depths.

Technical Specifications

General

Part Number

REN-900183

Product Name

Solar Fastener for Steel Substructure 125/50

Manufacturer

Renusol

Set Type

Pre-assembled

Construction

Material

Stainless steel

Weight

0.089kg

Dimension Code

125/50 (c/b)

Fixing

Screw Diameter

M10; 8.0mm

Thread Length

65.0mm

Screw Head

Hexagon head

Clamping Range (Module Thickness)

60.0mm – 105.0mm

Certification

MCS Certification

MCS012 IK0197/04

TÜV ID

1111212485

DIBt Building Approval

Z-14.4-555

Frequently Asked Questions

What steel section depth does this fastener suit?

The 125/50 variant covers a clamping range of 60.0mm to 105.0mm. Measure the steel purlin or substructure depth before ordering, as other Renusol variants (80/50 through 200/50) cover different ranges.

Does fitting this fastener require drilling into the steelwork?

No. The fastener clamps around the steel section using a setscrew, avoiding the need to drill into structural steel purlins.

What certification does this fastener carry?

It carries MCS012 IK0197/04, TÜV ID 1111212485, and DIBt building approval Z-14.4-555, supporting certified UK solar PV installations.

What screw size does this fastener use?

It uses an M10 screw with a 65.0mm thread length and a hexagon head.

What material is this fastener made from?

The fastener is manufactured entirely from stainless steel for long-term outdoor corrosion resistance.
