Humax MX7 7.4kW V2G Ready EV Charger with 5m Tethered Cable (HMX-A01T5)
The Humax MX7 is a cutting-edge, V2G-ready electric vehicle charger offering 7.4kW charging power on single-phase supply with a convenient 5m tethered Type 2 cable. Designed for residential use, the MX7 delivers smart, efficient, and flexible charging with comprehensive safety features and future-proof connectivity options. Built to withstand outdoor environments, this durable charger supports vehicle-to-grid and vehicle-to-home energy flows, making it an excellent choice for eco-conscious drivers.
Key Features
- 7.4kW charge power, single-phase 230V, 32A maximum current
- 5m tethered Type 2 charging cable included for hassle-free charging
- Vehicle-to-Grid (V2G) and Vehicle-to-Home (V2H) ready with ISO 15118 communication protocol
- Robust IP65 weatherproof rating and IK10 impact resistance
- Modern, wall-mounted design with removable swappable front fascia
- Built-in digital security lock and tamper protection
- Wi-Fi, Bluetooth Low Energy, and Ethernet communications; optional 4G connectivity
- Integrated RFID reader for secure access control
- Smart charging management and app control for scheduling and monitoring
- Compatible with all EVs and plug-in hybrid vehicles (PHEVs)
- 5-year manufacturer warranty for peace of mind
Technical Specifications
| Model | HMX-A01T5 |
|---|---|
| Output Power | 7.4kW |
| Charging Cable | 5m tethered Type 2 cable |
| Maximum Current | 32A |
| Operating Voltage | 230V AC Single Phase ±10% |
| Ingress Protection | IP65 |
| Impact Resistance | IK10 |
| Communication | Wi-Fi, Bluetooth LE, Ethernet, Optional 4G |
| Protocols | ISO 15118, OCPP 1.6J |
| Dimensions (HxWxD) | 335mm x 210mm x 132mm |
| Weight | Approx. 4.72kg |
| Operating Temperature | -30°C to +50°C |
| Warranty | 5 years (standard) |
| EAN | 5060321527288 |
Applications
- Residential EV charging with advanced smart features and V2G capabilities
- Supports efficient energy use with smart scheduling and renewable integration
- Provides secure access and user management via RFID
- Suitable for outdoor and indoor wall-mounted installations
Why Choose the Humax MX7 7.4kW?
- Robust, weatherproof design with impact resistance for durability
- Future-proofed V2G technology enabling energy export and sustainability benefits
- Advanced security and communication protocols for smart home integration
- Long-term warranty ensures peace of mind
