Grundfos Home Booster Unit MD300200 – 3 Bar Water Pressure Booster Set for Domestic Use

The Grundfos Home Booster Unit MD300200 is a high-quality single pump water pressure booster set, designed to enhance mains water supply pressure for domestic properties. Equipped with an integrated 200-litre stainless steel storage tank (180 litres usable volume) and a PM2 Pressure Manager controller, this unit reliably delivers up to 3 bar pressure to meet the demands of households with one to two bathrooms and standard fittings.

Why Buy the Grundfos Home Booster MD300200?

• Integrated Storage Tank: Features a 200-litre tank with 180 litres usable capacity for maintaining steady water supply and reducing pump cycling.
• Efficient Pressure Management: The PM2 Pressure Manager controls pump operation with on/off functionality, fault alerts, and protection against dry run and blockages.
• Reliable Performance: Delivers nominal 3 bar pressure (up to 3.6 bar max) with a maximum flow rate of 72 litres per minute (1.2 l/sec), suitable for typical domestic water demand.
• High-Quality Components: Stainless steel pump and WRAS-approved components ensure durability and compliance with water regulations.
• Compact and Ready to Install: Packaged as a ready-to-install unit with simple mains water, discharge, overflow, and electrical connections.
• Energy and Space Efficient: Compact floor-standing design with efficient pump motor sized at 588W, consuming 2.8 amps at full load.
• Modular Expandability: Multiple units can be combined for increased capacity or standby pumping in larger installations.
• Compliance and Safety: Includes a Type AB air gap in the tank, meeting Water Byelaws requirements and ensuring safe water supply.
• Manufacturer Warranty: 2-year guarantee for peace of mind.

Suitable For

• Domestic properties with one to two bathrooms requiring boosted mains water pressure.
• Homes with standard fittings including en-suites and cloakrooms.
• Households seeking a compact, efficient, and reliable pressure boosting solution.
• Situations requiring compliance with UK Water Regulations and WRAS approval.
• Properties with slow tank refill rates benefiting from optional slave tank expansion.

Technical Specifications

MPN: MD300200
EAN: 5710625340843
