Grundfos ALPHA2 GO 25-75 130 Circulator Pump | 93074268

Description

The Grundfos ALPHA2 GO 25-75 130 (93074268) is a high-efficiency circulator pump with an electronically commutated motor for heating and air conditioning systems. Built-in Bluetooth connects it to the Grundfos GO app for guided setup, compatibility checks and trend monitoring.

It is the premium model in the GO range, designed to replace stand-alone circulators and integrated UPM3 and UPM4 pumps, with a bright digital display showing live flow, head and power.

7.5 m

Maximum head

4.5 m³/h

Maximum flow

75 W

Maximum power

G 1½

Connection

130 mm

Port-to-port length

Bluetooth

Grundfos GO app

Replacement made simple

Grundfos states the ALPHA2 GO 25-75 130 suits most UPM3 and UPM4 pumps and the majority of stand-alone circulators. Use the GO app to verify compatibility and match pump curves.

Check compatibility first

When replacing an integrated UPM3 or UPM4, an FCI signal adapter cable may be needed. Confirm the port-to-port length (130 mm) and connection thread against the old pump before ordering.

Safety

Isolate the electrical supply before working on the pump and allow the system to cool. Electrical connection must be carried out by a competent person in line with BS 7671.

Key features

Four control modes

Constant pressure, proportional pressure, constant flow and constant curve with adjustable setpoints cover radiator, underfloor and mixed systems.

AUTOADAPT

AUTOADAPT selects an energy-efficient setting automatically for radiator and underfloor heating systems.

Guided setup in the GO app

Bluetooth connection to the Grundfos GO app gives guided setup, compatibility checks and trend data for long-term optimisation.

Digital display

A bright digital display shows real-time flow rate, head and power consumption for commissioning and fault finding.

Toolless installer plug

The included toolless installer plug speeds up the electrical connection on site.

Robust and quiet

Self-venting, dry-running protection and a robust start-up help it resist blockage from dirt, limescale and magnetite.

Specification

General

Brand

Grundfos

Model

ALPHA2 GO 25-75 130

Manufacturer part number

93074268

Application

Heating and air conditioning circulation

Hydraulic

Connection

G 1½

Port-to-port length

130 mm

Maximum head

7.5 m

Maximum flow

4.5 m³/h

Electrical

Supply

220-240 V

Maximum power

75 W

Motor

Electronically commutated (ECM)

Controls and connectivity

Control modes

Constant pressure, proportional pressure, constant flow, constant curve

Auto function

AUTOADAPT

Connectivity

Built-in Bluetooth, Grundfos GO app

Display

Digital: flow, head, power

Frequently asked questions

What can the ALPHA2 GO 25-75 130 replace?

It is designed to replace UPM3 and UPM4 integrated pumps and most stand-alone circulators. Use the GO app to verify compatibility.

Do I need the app to commission it?

The pump has its own display and controls, but the Grundfos GO app gives guided setup and trend data.

Is it suitable for underfloor heating?

Yes. AUTOADAPT has a dedicated underfloor mode, and four control modes cover radiator and underfloor systems.

What is the 130 in the name?

It is the port-to-port length in millimetres.

Does it include an electrical plug?

Yes, it includes a toolless installer plug for quick electrical connection.
