Enphase IQ8AC 54 to 72 Cell Microinverter 366 VA Peak Power MC4
Product Description
The Enphase IQ8AC Microinverter is engineered to support 54-cell, 60-cell, 66-cell, and 72-cell high-output PV modules. With a peak output of 366 VA and integrated MC4 connectors, it's built for modern solar panels including bifacial, half-cell, and ultra-high power formats. Designed for safety, reliability, and performance, it enables panel-level control, monitoring, and rapid shutdown in one compact and efficient unit.
- Smart Grid Ready: Supports advanced grid services and remote firmware updates.
- High Conversion Efficiency: Up to 97.3% peak efficiency with excellent thermal performance.
- MC4 Integration: Pre-installed MC4 connectors for easy plug-and-play installation.
- Rapid Shutdown Compliant: Enhances system safety and meets electrical code requirements.
- Modular Design: Connects quickly with Enphase cabling system for scalable installations.
- Long-Term Durability: Backed by a 25-year limited warranty.
Key Technical Specifications
| Peak Output Power | 366 VA |
| Continuous Output Power | 360 VA |
| Input Voltage Range (MPPT) | 28 – 45 V |
| Max DC Input Current | 14 A |
| Short-Circuit Current | 25 A |
| Compatible Module Types | 54–72 cell and equivalent half-cut modules |
| Connector Type | MC4 |
| Max Efficiency | 97.3% |
| EU Efficiency | 96.6% |
| AC Output Voltage | 230 V |
| AC Frequency | 50 Hz |
| Dimensions | 212 × 175 × 30.2 mm |
| Weight | 1.1 kg |
| Operating Temperature Range | -40°C to 65°C |
| Protection Class | Class II (double insulated) |
| Enclosure Rating | IP67 |
| Warranty | 25 years |
Applications
- Residential solar systems with varying panel orientations or shading
- Commercial projects requiring module-level monitoring and rapid shutdown
- Installations using high-power or bi-facial PV modules
What's Included
- 1 × Enphase IQ8AC Microinverter (IQ8AC-72-M-INT)
- Built-in MC4 input connectors
- Mounting bracket (if required by installer)
- User and installation documentation
Why Choose the Enphase IQ8AC?
- Designed to work with powerful new-generation panels up to 530W
- Provides per-panel monitoring, safety, and fast servicing
- Future-ready with remote-grid configurability and smart energy features
- Trusted Enphase quality backed by a 25-year warranty
- Type Solar
- Vendor Enphase
- SKU IQ8AC-72-M-INT
