GivEnergy 3-Phase 11kW Hybrid Inverter

GivEnergy 3-Phase 11kW Hybrid Inverter

The GivEnergy 3-Phase 11kW Hybrid Inverter is a high-performance, all-in-one solution for integrating solar PV and battery storage in commercial and large residential applications. This hybrid inverter supports both AC and DC coupling, enabling flexible system design and maximum energy self-consumption. With seamless backup capability, advanced monitoring, and a robust 12-year warranty, it is ideal for projects requiring reliability, efficiency, and future-proof energy management.

Key Features

• Nominal AC Output Power: 11,000W (11kW)
• Max. Apparent Power Output to Grid: 11,000VA
• Max. PV Input Power: 15,000W (15kWp)
• Max. PV Input Voltage: 1000V
• MPPT Voltage Range: 200V – 850V
• No. of MPPTs / Strings per MPPT: 2 / 1
• Max. Input Current (per string): 15A
• Max. Short Circuit Current (per string): 20A
• Battery Voltage Range: 200VDC – 600VDC
• Max. Charge/Discharge Power: 11,000W
• Charge/Discharge Current: 25A
• Battery Type: LiFePO4
• AC Connection: Three Phase (400/380VAC, 3W/N/PE)
• Max. Output Current: 16.5A
• Frequency Range: 50 / 60 Hz
• Automatic Switch Time (EPS): <20ms
• Power Factor (Full Load): >0.99
• THDI (Nominal Power): <3%
• Max. Efficiency (PV): 97.9%
• Euro Efficiency: 97%
• MPPT Efficiency: 99.9%
• Charge/Discharge Efficiency: 97.6% / 96%
• Protection Class: IP65 (indoor/outdoor)
• Noise Emission (Typical): <30dB
• Weight: 35 kg
• Dimensions (HxDxW): 658 × 214 × 480 mm
• Operating Temperature: -25°C to +60°C (derating above 50°C)
• Relative Humidity: 0–100%
• Altitude: up to 4000m (derating above 2000m)
• Self-Consumption: <15W
• Inverter Topology: Transformerless
• Display: LCD, LED & App
• Communications: BMS: CAN, Meter: RS485, Portal: WiFi (USB)
• Warranty: 12 years (manufacturer)
• Certifications: CE, UKCA, IEC 62109-1&2, EN50549, G98, G98/NI, G100, CEI 0-21, VDE 0124, N4105

Note: The GivEnergy 3-Phase 11kW Hybrid Inverter is suitable for large residential and commercial installations, offering advanced energy management, seamless backup, and compatibility with high voltage LiFePO4 batteries. Professional installation is required.
